Chat & generation

The core loop: load a LiteRtEngine, create a LiteRtConversation, send turns. This guide covers the generation features in depth — function calling, reasoning mode, multimodal input, and token counting. Conversation persistence has its own guide, as do speculative decoding and engine tuning.

using LiteRtLmSharp;

using var engine = LiteRtEngine.Load(new LiteRtEngineOptions
{
    ModelPath = "gemma-4-E2B-it.litertlm",   // from huggingface.co/litert-community
    Backend = LiteRtBackend.Cpu,              // or .Gpu (WebGPU -> D3D12/Vulkan/Metal)
    MaxNumTokens = 4096,                       // total context window
});

using var chat = engine.CreateConversation();

// Blocking:
Console.WriteLine(chat.Send("Hello!").Text);

// Awaitable (pass a CancellationToken to cancel mid-generation):
Console.WriteLine((await chat.SendAsync("Hello!")).Text);

// Streaming: each piece is tagged (answer / thinking / tool call) — see Reasoning mode below.
await foreach (var chunk in chat.SendStreamingAsync("Tell me a joke"))
    Console.Write(chunk.Text);

Function calling

using var chat = engine.CreateConversation(new LiteRtConversationOptions
{
    Tools = [ new LiteRtTool("get_weather", "Get weather for a city",
        """{"type":"object","properties":{"location":{"type":"string"}},"required":["location"]}""") ],
    EnableConstrainedDecoding = true,
});

var r = chat.Send("Weather in Tokyo?");
if (r.IsToolCall)
{
    var results = r.ToolCalls.Select(c => new LiteRtToolResult(c.Name, RunTool(c)));
    Console.WriteLine(chat.SendToolResults(results).Text);
}

EnableConstrainedDecoding grammar-constrains the model's output to valid tool-call JSON — on small models it is the difference between reliable and flaky arguments. If you use the Microsoft.Extensions.AI or Semantic Kernel connectors, their auto-invocation layers sit on top of this same API.

The MAUI sample's Tools tab: the model calls the device battery API and answers with the real value

Function calling on a phone: the model calls the device's real battery API and answers with the result.

Reasoning mode (thinking)

Models with a reasoning template (the Gemma builds) can be told to think before answering:

using var chat = engine.CreateConversation(new LiteRtConversationOptions
{
    EnableThinking = true,             // Gemma reasoning mode (sets enable_thinking)
    FilterThinkingFromKvCache = true,  // keep the (long) reasoning out of the context window
});

The reasoning trace comes back separate from the answer — on the blocking Send via response.Thinking (and the full response.Channels map), and when streaming each LiteRtStreamChunk is tagged by Kind (Answer / Thinking / ToolCall):

await foreach (var chunk in chat.SendStreamingAsync("Why is the sky blue?"))
    Console.Write(chunk.IsThinking ? $"\n[thinking] {chunk.Text}" : chunk.Text);

Reasoning mode is set per-conversation via extra context; for arbitrary template variables use the raw ExtraContext (a JSON-object string) escape hatch; on a model whose template does not use enable_thinking it is a harmless no-op.

Multimodal messages (image / audio)

On a multimodal model (the Gemma 4 E-series are text + vision + audio), enable the encoder backends at load time and attach images or audio clips to a turn. The model decodes the bytes — no format hint is sent.

using var engine = LiteRtEngine.Load(new LiteRtEngineOptions
{
    ModelPath = "gemma-4-E2B-it.litertlm",
    Backend = LiteRtBackend.Cpu,
    VisionBackend = LiteRtBackend.Cpu,   // enables image input; null = off
    AudioBackend = LiteRtBackend.Cpu,    // enables audio input; null = off
    MaxNumTokens = 4096,     // leave room for the media's tokens (an image is ~256)
});
using var chat = engine.CreateConversation();   // a plain conversation can send attachments

// Attach in-memory bytes (sent as a base64 blob) ...
byte[] png = File.ReadAllBytes("cat.png");
var reply = chat.Send("What is in this image?", [LiteRtAttachment.Image(png)]);

// ... or a file on disk (memory-mapped natively, no base64 — desktop):
chat.Send("Describe this photo.", [LiteRtAttachment.ImageFile("/photos/sunset.jpg")]);

// Audio works the same way; streaming has matching attachment overloads:
await foreach (var chunk in chat.SendStreamingAsync(
                  "Transcribe this.", [LiteRtAttachment.Audio(wavBytes)]))
    Console.Write(chunk.Text);

Attachments follow the text in content-part order; pass several to interleave them. Cap how much of the context window an image consumes with LiteRtConversationOptions.VisualTokenBudget. Vision runs on CPU or GPU; some models constrain their audio backend (Gemma 4's audio sub-model requires CPU, so AudioBackend = LiteRtBackend.Gpu fails engine creation for it on any platform) — keep audio on CPU when the main backend is GPU. A plain CreateConversation() can send attachments: the binding configures the conversation for the engine's encoders automatically, so you don't have to set a sampler or output cap. Just give MaxNumTokens room for the media's tokens (an image is ~256). If a send still hits a multimodal-setup problem the binding throws a LiteRtException naming the likely causes (model not multimodal, VisionBackend / AudioBackend unset, or MaxNumTokens too small). The MAUI sample's Chat tab exposes 📷 / 🎵 attach buttons (and a modality indicator) for capable models. Wire-format and validation details: native-abi.md.

Token counting (tokenize / detokenize)

Measure a prompt's exact token cost, or convert between text and token ids, without running inference. Useful for budgeting against MaxNumTokens before sending.

int[] ids = engine.Tokenize("How many tokens is this?");
Console.WriteLine($"{ids.Length} tokens");      // exact count, no generation
string text = engine.Detokenize(ids);           // back to text (surface form)

// The model's start (BOS) and stop (EOS) tokens, each a literal string or a sequence of ids:
foreach (var stop in engine.GetStopTokens())
    Console.WriteLine(stop);                     // e.g. an EOS token id like [1]

These call the model's own tokenizer, so the counts match what generation sees. Tokenize returns the raw ids (no chat template); Detokenize returns the tokenizer's surface form, so SentencePiece models (the Gemma builds) render word boundaries as ▁. A start/stop token is a LiteRtTokenUnion carrying either Text or Ids (its Kind says which).

A common use is keeping a conversation inside its context window. The window holds the whole chat (prompt plus replies, across turns), and overflowing it degrades output, so measure the next turn in real tokens and react before sending instead of guessing by string length:

// contextWindow is the MaxNumTokens you loaded with; leave headroom for the reply.
int next = engine.Tokenize(message).Length;
if (chat.TokenCount + next > contextWindow - replyHeadroom)
    // won't fit: warn the user, shorten the message, or drop old turns and reload via History.
    Warn("Context almost full — shorten the message or start a new chat.");

Tokenize counts the raw text; for the exact per-turn cost with the chat template included, render the message first with chat.RenderMessage(text) (it returns the templated prompt without sending), then tokenize that: engine.Tokenize(chat.RenderMessage(text)).Length.

Runnable demos

See samples/Console (--tools for the function-calling loop, --spec for speculative decoding, --thinking for reasoning mode) and samples/Maui for a full Android/Windows chat app with model download, streaming, tools and multimodal attachments.
